Batch B03 — A/B drive units + front idlers

Time: 8.5 h · Sessions: 1 plate start · Steps: 5

Start the chapter · Resume · Read the whole chapter on one page

StartBefore you start

Step B03.1Filament prep

Step B03.2Load plate B03-P1 (both sides)with a helper

Step B03.3Print plate B03-P1

Step B03.4Inspect

Step B03.5Sort into binswith a helper

Checkpoint B03Tick before moving on

Gather per session — what to lay out before each bench segment.

• Steps B03.1–B03.3 · ~5 min — 8 objects — 8.5 h, 119 g (PrusaSlicer 2.9.6 estimate) · a_drive_frame_lower — from bin 04-A · a_drive_frame_upper — from bin 04-A · front_idler_right_lower — from bin 04-A · front_idler_right_upper — from bin 04-A · b_drive_frame_lower — from bin 04-B · b_drive_frame_upper — from bin 04-B · front_idler_left_lower — from bin 04-B · front_idler_left_upper — from bin 04-B
• Step B03.4 · ~10 min — nothing to lay out
• Step B03.5 · ~10 min — nothing to lay out
